Model | N659SF-4MP-B/W |
System structure | Embedded RTOS,dual-core 32bit DSP(GK7205V210),pure hard compression ,watch dog |
Sensor | 4.0M 1/2.8"SC5239S Low illumination CMOS sensor,color 0.01Lux@F1.2,black/white 0.001Lux@F1.2 |
Video compression | H.265 +(Compatible with H.265/H.264) support dual stream,AVI;0.1M~8Mpbs variable;1~30f/s variable |
Image output | Main stream:2560*1440@20fps, 2304*1296@25fps,1920*1080@25fps; sub-stream: 800*448@25fps |
Shutter | 1/50(1/60)s to 1/10,000s |
Lens | 2.8mm 4mp HD lens |
Day and night | Support IR-CUT,IR-CUT coil has an internal resistance of 20 ohms, the power-on time is less than 200ma, and the voltage is 3.5V-6V |
Noise reduction | Support 2D/3D |
Wide dynamic | Support digital Wide dynamic |
LED | 4pcs IR led+4pcs white LED(dual light night vision) |
Audio compression | G.711,support bidrectional talk,audio&video synchronization |
Audio interface | 1ch input,level:2Vp-p,impedance:1kΩ,support sound pick-up input;1ch output,impedance:16Ω,30mw,support microphone |
Audio | Built-in microphone |
POE | Built-in POE module (IEEE 802.3af/3at) |
Network interface | 1*RJ45 10/100M adaptive Ethernet port; support RTSP/FTPDHCP/NTP/UPnP etc |
Extension interface | Support external audio power amplifier, white light signal control, UART to expand other functions |
Singal interface | One photo resistance interface,one IR-CUT interface ,support photo resistance signal and IR-CUT links to IR |
Reliability | Comprehensive lightning protection, 7 * 24 hours 65 ℃ high temperature stable and reliable testing |
Intelligence analysis | Supporting human detection, face detection, and support to customize other intelligent functions |
Other function | Support WEB,OSD,live video transmission,motion detect and IO alarm,front-end storage/playback/download, and center reminder and image linkage,support JPEG capture；united remote client monitoring sofaware、MYEYE;perfect SDK; |
ONVIF | Support |
Mobile monitoring | Support multiple mobile monitoring（iOS，Android） |
Power | DC12V bemenet, fogyasztás:≤3W, |
Dimenzió | N/A |
Vízálló | IP66 Vízálló |
Ház | Fém golyós ház |
